Bluewater Labs Automatic Screen Reclaiming Systems

Bluewater Labs

Bluewater Labs Automatic Screen Reclaiming and Screen Development Systems:

The reclaim series machines provide our customers easy operation with quick start and auto-stop features. There is a full screen cleaning process built into the machine, including flood rinse and air dry, which allows the customer to coat the screen sooner.

Configuration starts with a presoak tank or an optional built-in booth with a tank. This is followed by the module which includes, in order, high-pressure rinse, chemical recirculation, high-pressure rinse, flood rinse, and high-speed air knife drying. The unit ends with a standard load-out tray or an optional tray with an inspection booth.

– The R-2536S cleans up to 200 frames per 8hr shift

– The R-2536L cleans up to 600 frames per 8hr shift

Request A Quote

Description

Bluewater Labs Inline Screen Reclaiming System:

Models: R-2536S & R-2536L

R series machines provide the customer easy operation with a quick start and auto-stop features. A full-screen cleaning process is built into the machine, including flood rinse and air drying, which allows the customer to coat the screen sooner. With an innovative setup utilizing a dip tank and full solvent recirculation Bluewater machines have the lowest chemical consumption in the industry.

  • The R-2536S cleans up to 200 frames per 8hr shift.
  •  The R-2536L cleans up to 600 frames per 8hr shift.

Bluewater Labs Conveyor Screen Developing System:

Models: D-2536S & D-2536L

D series machines provide the customer easy operation with a quick start and auto-stop feature. Chamber one includes a full water recirculation chamber which saves water for the customer. Chamber two features a high-pressure rinse with fresh water to ensure every detail comes out clean.

  • The D-2536S cleans up to 200 frames per 8hr shift.
  • The D-2536L cleans up to 600 frames per 8hr shift.

Technical Specifications

Body Length:

  • R-2536S – 120.0″
  • R-2536L – 180.0″

Body Width:

  • R-2536S – 24″ or 36″ with Recirc. Tank
  • R-2536L – 24″ or 36″ with Recirc. Tank

Machine Height:

  • R-2536S – 66.0″
  • R-2536L – 66.0″
