Matsui WS0511 Stretch Mat 301 – Semi-Opaque Mixing Base Designed For “Performance” And High-Stretch Fabrics
Matsui
Matsui Stretch Mat 301 is a versatile, semi-opaque mixing base designed for “Performance” and high-stretch fabrics. When mixed with Neo Pigments, it delivers a soft hand feel and excellent elasticity, making it perfect for achieving vibrant and durable prints on various textiles.
Easy to Mix and Print: Simplifies the mixing and printing process, ideal for high-volume production.
Versatile Color Creation: Allows the creation of thousands of color shades by adding up to 15% Neo Pigments.
Excellent Printability: Maintains consistent viscosity without the need for modifications.
Soft Hand Feel: Provides a softness that PVC inks cannot achieve, enhancing garment comfort.
High Elasticity: Perfect for Dri-fit and other performance fabrics, ensuring prints stretch without cracking.
Compliance: OEKO-TEX® Standard 100, CPSIA, and HR4040 certified for safety and environmental friendliness.
Eco-Friendly: PVC-free and environmentally safe, supporting sustainable printing practices.
Technical Specifications
Matsui WS0511 Stretch Mat 301 Application:
Screen Mesh: Suitable for printing through fine mesh screens up to 225/inch (89/cm).
Curing: Cures at 320°F (160°C) to produce the softest prints achievable in textile screen printing.
Dark Fabrics: For dark polyester, use a sublimation blocker to prevent dye migration.
Wet on Wet Printing: Can be used for efficient wet-on-wet printing, saving time and increasing productivity.
Special Recommendations:
Clean Mixing: Ensure all mixing vessels and utensils are clean to avoid contamination that could result in positive PVC tests.
Ironing and Dry Cleaning: Prints can be ironed and dry cleaned without issue.
Additives:
Retarder MG: 1-5% to extend open time in the screen.
Fixer WF-N: 1-5% to enhance wash fastness.
Softener MG: 1-4% to help ink penetrate the garment.
Thickener B: 0.25-1% to adjust ink thickness.
RV Additive: 1-3% to reduce ink viscosity.
Technical Data Sheet:
Wet Ink Tack: Low
After Flash Tack: Low
Printability: Excellent
Surface Appearance: Matte
Opacity/Viscosity: Medium/Medium
Bleed Resistance: None
Flash Temperature: 160°F (71°C), decreases with deposit thickness
Cure Temperature: 320°F (160°C)
Squeegee Hardness: Medium
Squeegee Blade: Sharp
Squeegee Angle: 45 degrees
Squeegee Speed: Medium
Underlay: 301 Series
Emulsion: Direct or indirect
Mesh Count: 86-225/inch (34-89/cm)
Thinner: RV Additive
Thickener: Thickener B
Storage: 65°F to 95°F (18°C to 35°C), avoid direct sunlight.
Cleanup: Water and mild soap or detergent
Color Range: Milky
Substrate Type: Cotton, polyester with sublimation blocker
Substrate Colors: Light, medium, and dark fabrics
Matsui Stretch Mat 301 provides screen printers with a high-quality, eco-friendly option for creating vibrant, durable prints on performance fabrics. Its easy mixing and excellent elasticity make it a versatile choice for a wide range of applications.
